Description
Standard equipment
On the dome:
. Trap diam. 400 mm
. 25 DIN NW tap for adapter / pressure regulator attachment
On the shell:
. Double wall, water connection 2 x 1 “male on the back
. Dog tag
. 2 taps 10 DIN (for tap / thermowell / thermometer)
On the background :
. Pricking draw clear male 1 “
. 1 “male total drain hose attached to the front
. Stainless steel frame with 3 welded feet and fixing plates
Finishing:
.304 stainless steel
. Interior finish IIId / 2R – bright annealed
. Shell finish: brushed / bottom and dome: frosted
Accessories included:
. TÜV costs (state technical inspection service – compulsory)
. 2 ball valves stainless steel 1 “/ male 1” without cap
. Tasting tap
. Glove finger and thermometer on the front
. T-adapter with CO2 valve and PICOLINO pressure regulator 3/4 ” . Safety valve
